Construction : Black steel chassis with aluminum heat-sink
Color : Black
CPU Type Optional : Intel Atom D525 1.8GHz
Memory Optional : 1x DDR3 SO-DIMM slot, up to 4GB 800 MHz
Chipset : Intel ICH8M
HDD Optional : 1 x 2.5" SATA2
Flash Disk Optional : 1 x Internal CF slot
|
External I/O :
LAN : 2 x GbE RJ-45
Serial : 2 x RS-232 DB9, 1 x RS-232/422/485 selectable default RS-485
USB : 4 x USB 2.0 type A
KB/MS : none
Audio : 1 x Line out phone jack
Expansion BUS : On board expansion bus 1 x Mini-PCIe full size
AC Input Voltage : 12V DC/ Option: 11~32V DC
Fanless : yes
Other Features : 1 x VGA, CE/FCC class A
|
